Changeover Switch Kohler SDMO Generator Sets

Kohler-SDMO Kohler-SDMO

R05M

New

The manual changeover switch is used to connect and disconnect a generating set manually to a domestic circuit when there is a power cut.

* Only for single-phase groups

Available

€58,50 tax incl.

€58,50 tax excl.

€65,00

Caja Transporte Asvarta

Distribuidores Oficiales Kohler y Lombardini

Kohler and Lombardini official distributors

discounts

10%discount on orders from €100
15%discount on orders from €300
20%discount on orders from €500

The discount is applied automatically in the cart.

Shipping to Spain and Portugal

Mainland Spain and Portugal

€9.50

Balearic Islands, Ceuta and Melilla

€9.50

Canary Islands

from

€37

Depending on parcel weight

Canary Islands rates by weight

0 to 10 kg10 to 75 kg75 to 150 kgOver 150 kg
€37€67€127€222

International shipping

Rates depend on the destination and the total weight of the parcel. Click each zone to see prices and the countries included.

European Unionfrom €17
Zone0 to 10 kg10 to 75 kg75 to 150 kgOver 150 kg
Zone 1€17€32€62€92
Zone 2€32€62€122€142
Zone 3€37€67€127€222

Zone 1: Germany, Belgium, Denmark, Slovakia, France, Ireland, Italy, Luxembourg, the Netherlands, Poland and Sweden.

Zone 2: Austria, Croatia, Estonia, Finland, Latvia, Lithuania and the Czech Republic.

Zone 3: Bulgaria, Cyprus, Slovenia, Hungary, Malta and Romania.

Europe outside the EUfrom €35
0 to 10 kg10 to 75 kg75 to 150 kgOver 150 kg
€35€65€125€220

Countries included: Norway, the United Kingdom, Switzerland, Albania, Belarus, Bosnia and Herzegovina, North Macedonia, Moldova, Montenegro, Serbia, Ukraine, Turkey, Gibraltar, Vatican City, Liechtenstein, Monaco, San Marino, Guernsey, Jersey and Andorra.

Africafrom €60
0 to 10 kg10 to 75 kg75 to 150 kgOver 150 kg
€60€120€200€370

Countries included: Angola, Algeria, Benin, Botswana, Burkina Faso, Burundi, Cape Verde, Cameroon, Chad, Comoros, Congo, Ivory Coast, Egypt, Eritrea, Eswatini (Swaziland), Ethiopia, Gabon, Gambia, Ghana, Equatorial Guinea, Guinea-Bissau, Kenya, Lesotho, Liberia, Libya, Madagascar, Malawi, Mali, Morocco, Mauritius, Mauritania, Mayotte, Mozambique, Namibia, Niger, Nigeria, Central African Republic, Democratic Republic of the Congo, Réunion, Rwanda, São Tomé and Príncipe, Senegal, Seychelles, Sierra Leone, Somalia, South Africa, Sudan, Tanzania, British Indian Ocean Territory, Togo, Tunisia, Uganda, Yemen, Djibouti, Zambia and Zimbabwe.

Asia and Oceaniafrom €70
0 to 10 kg10 to 75 kg75 to 150 kgOver 150 kg
€70€180€280€400

Countries included: Israel, Bangladesh, Bhutan, Myanmar, Brunei, Nepal, Sri Lanka, Armenia, Azerbaijan, Georgia, Kazakhstan, Kyrgyzstan, Turkmenistan, Uzbekistan, Singapore, Thailand, Taiwan, Mongolia, Hong Kong, the Philippines, Indonesia, Malaysia, Japan, South Korea, India, Saudi Arabia, Bahrain, the United Arab Emirates, Jordan, Kuwait, Lebanon, Oman, Pakistan, Qatar, China, Laos, Macao, East Timor, Vietnam, Afghanistan, North Korea, the Palestinian Territories, Iraq, Tajikistan, Cambodia, Iran, Russia, Australia, Norfolk Island, New Zealand, the Cook Islands, Fiji, Guam, the Northern Mariana Islands, Kiribati, the Marshall Islands, Micronesia, New Caledonia, Palau, Papua New Guinea, French Polynesia, the Solomon Islands, Samoa, American Samoa, Tuvalu, Vanuatu, Wallis and Futuna, the Maldives, Tonga, Nauru, Niue and the French Southern Territories.

North Americafrom €90
0 to 10 kg10 to 75 kg75 to 150 kgOver 150 kg
€90€200€300€450

Countries included: the United States, Mexico, Canada and Saint Pierre and Miquelon.

Central and South America and islandsfrom €80
0 to 10 kg10 to 75 kg75 to 150 kgOver 150 kg
€80€190€290€400

Countries included: Puerto Rico, Belize, Costa Rica, El Salvador, Guatemala, Haiti, Honduras, Nicaragua, the Dominican Republic, Chile, Argentina, Brazil, Bolivia, Panama, Paraguay, Peru, Uruguay, Venezuela, Colombia, Ecuador, Anguilla, Antigua and Barbuda, Aruba, the Bahamas, Barbados, Bermuda, Dominica, Grenada, Guadeloupe, Guyana, the British Virgin Islands, the US Virgin Islands, Jamaica, Martinique, Montserrat, Saint Martin, Saint Vincent and the Grenadines, Saint Lucia, Trinidad and Tobago, the Netherlands Antilles, South Georgia and the South Sandwich Islands, Saint Barthélemy, the Turks and Caicos Islands, the Cayman Islands, Saint Kitts and Nevis, Cuba, French Guiana and Suriname.

Nordic islandsfrom €120
0 to 10 kg10 to 75 kg75 to 150 kgOver 150 kg
€120€230€350€550

Countries included: Iceland, Greenland and the Faroe Islands.

Questions about your shipment? Call us or message us on WhatsApp at +34 644 427 935.

GENERAL SPECIFICATIONS

  • Engine brand MITSUBISHI
  • KOHLER alternator trademark
  • Voltage (V) 400/230
  • Control panel APM303
  • Optional Box APM403
  • Optional Box M80
  • Optional box Terminal strip
  • Type of cooling Radiator
  • Class of performance G1

DIMENSIONS COMPACT VERSION

  • Length (mm) 1405
  • Width (mm) 715
  • Height (mm) 1053
  • Tank capacity (L) 50
  • Net weight (kg) 387

DIMENSIONS SOUNDPROOFED VERSION M126

  • Soundproofing type M126
  • Length (mm) 1750
  • Width (mm) 775
  • Height (mm) 1230
  • Tank capacity (L) 50
  • Net weight (kg) 530
  • Sound pressure level @1m in dB(A)
  • 50Hz (75% PRP) 71
  • Sound pressure level @7m in dB(A) 58

General

  • Engine brand MITSUBISHI
  • Ref. Engine S3L2-SD *
  • Atmo Suction Type
  • Diesel fuel
  • Cylinder arrangement L
  • Number of cylinders 3
  • Displacement (l) 1,32
  • Diameter (mm) * Stroke (mm) 78 * 92
  • Compression ratio 22 : 1
  • Speed (tr/mn) 1500
  • Max. auxiliary power at nominal speed (kW) 11.20
  • Frequency regulation (%) +/- 2.5%
  • Type of injection Indirect
  • Type of control Mechanical
  • Air filter type, Dry models

Fuel system

  • Maximum flow rate of fuel oil pump (l/h) 18
  • Max. pressure in fuel circuit (m) 1.50
  • Consumption with fan
  • Consumption 110% load (l/h) 0
  • Consumption 100% PRP load (l/h) 3.10
  • Consumption 75% PRP load (l/h) 2.50
  • Consumption 50% PRP load (l/h) 2.10

Lubrication system

  • Oil capacity (l) 4,20
  • Min. oil pressure (bar) 0.50
  • Max. oil pressure (bar) 4
  • Oil sump capacity (l) 3,70
  • Oil consumption 100% ESP 50Hz (l/h) 0.02
  • Air intake system
  • Max. inlet back pressure (mm H2O) 200
  • Combustion air flow rate (l/s) 13.60

Cooling system

  • Engine and radiator capacity (l) 4.20
  • Fan power (kW) 0.40
  • Fan air flow rate (m3/s) 0.50
  • Radiator back pressure (mm H2O) 10
  • Type of cooling Glycol-Ethylene
  • Radiated heat (kW) 1
  • Heat expelled in the water HT (kW) 10
  • Water temperature at outlet (°C) 93
  • Engine stop water temperature (°C) 111
  • Start of opening of HV thermostat (°C) 82
  • Total opening of the HV thermostat (°C) 95

Alternator specifications

  • KOHLER alternator trademark
  • Ref. Alternator KH00350T
  • Number of poles 4
  • Number of bearings
  • Ring and brushless technology
  • IP23 protection rating
  • Insulation class H
  • Number of threads 12
  • Ability to maintain a
  • short circuit at 3 In for 10 s
  • Yes
  • AVR adjustment Yes
  • Direct Coupling

Application data

  • Excess speed (rpm) 2250
  • Power factor (Cos Phi) 0.80
  • Regulating the voltage to the regime
  • established (+/- %) 1
  • Waveform: NEMA=TIF <45
  • Waveform: IEC=FHT <2
  • Total harmonic distortion in
  • vacuum DHT (%) 2.6
  • Total harmonic distortion in
  • DHT load (%) 2.3
  • Response time (Delta U = 20%)
  • transitional) (ms) 200
