Generator Set Diesel 6000 A XL C5 Kohler SDMO

Diesel 6000 A XL SDMO

Thanks to the oil safety of the Diesel range, with a turn of the key not only will the engine start but it will not start and will stop during operation if the oil level is not adequate. Its autonomy allows a use during a prolonged useful life able to face all the professional applications.

Enjoy the maximum performance of your SDMO Generator Set Diesel 6000 A XL C5 thanks to the performance and power of the integrated Kohler engines.

Several supported uses:

• Ideal for small vehicles
• For cultivators
• Agriculture
• Do-it-yourself
• Construction
• Industrial purposes

Find more SDMO generators in our SDMO Spain catalogue to find the alternative you are looking for.

All the advantages of Diesel 6000 A XL C5

We list all the advantages:

• Warranty applied for three years.
• Air-cooled thanks to its professional Kohler engine.
• Long autonomy thanks to the Diesel range
• Maintenance-free electric starter batteries.
• Comfortable grip thanks to ergonomic handles.

Included accessories SDMO Diesel 6000 A XL C5

Accompanied by the purchase of your generator set we include the following complements without additional cost:

• User and maintenance manual.
• Battery without maintenance.
• Ergonomic non-slip handles.
• Elements for better surface stability.

You can complement your Kohler SDMO Diesel 6000 A XL C5 with the optional accessories below.

ENGINE SPECIFICATIONS

• Engine brand KOHLER DIESEL
• Engine type KD15-440E_C5
• Distribution Diesel O.H.V.
• Start Electrical
• Oil shutdown Oui
• Displacement (cm3) 442
• Oil system capacity including filters (L) 1,50

ALTERNATOR SPECIFICATIONS

• Technology Brushless
• AVR Regulation No
• Indication of protection IP 23
• Insulation class H

PLUGS AND PANEL DESCRIPTIVE

• 1 230V 10/16A socket - circuit breaker + 1 230V 32A socket - circuit breaker + indicator + APM202

DIMENSIONS AND WEIGHT

• Length (cm) 81
• Width (cm) 55,50
• Height (cm) 59
• Dry Weight (kg) 103

PACKAGING

• Packaging type Box
• Length (cm) 82
• Width (cm) 56,50
• Height (cm) 60
• Weight (kg) 106
• Pallet type 120/80
• Number of box by pallet 6
• Pallet height (cm) 193
• weight of the packaged Pallet (kg) 646

SHIPPING IN SPAIN AND PORTUGAL

IBERIAN PENINSULA (SPAIN AND PORTUGAL)

Shipping cost: 7,50 €

Balearics, Ceuta and Melilla

Shipping cost: 9,50 €

Canary Islands

Shipping rates to the Canary Islands depend on the weight of the package:

Shipping to European Union

*Zone 1: Germany, Belgium, Denmark, Slovakia, France, Ireland, Italy, Luxembourg, Netherlands, Poland, Sweden

**Zone 2: Austria, Croatia, Estonia, Finland, Latvia, Lithuania, Czech Republic

**Zone 3: Bulgaria, Cyprus, Slovenia, Hungary, Malta, Romania

Shipments to Europe to non-European Union Countries (*1)

Shipping to África (*2)

Shipping to Asia y Oceanía (*3)

Shipping to North América (*4)

Shipping to Central, South America and Islands (*5)

Shipping to Nordic Islands (*6)

(*1) No EU: Norway, United Kingdom, Switzerland, Albania, Belarus, Bosnia and Herzegovina, Macedonia, Moldova, Montenegro, Serbia, Ukraine, Turkey, Gibraltar, Vatican City, Liechtenstein, Monaco, San Marino, Guernsey, Jersey,

(*2) Africa: Morocco, Equatorial Guinea, Algeria, Egypt, South Africa, Chad, Gambia, Central African Republic, Tunisia, Yemen, Sudan, Angola, Benin, Botswana, British Indian Ocean Territory, Burkina Faso, Burundi, Cape Verde, Cameroon, Democratic Republic of Congo, Republic of Congo, Ivory Coast, Djibouti, Eritrea, Ethiopia, Gabon, Ghana, Guinea-Bissau, Kenya, Lesotho, Liberia, Madagascar, Malawi, Mali, Mauritius, Mauritania, Mozambique, Namibia, Niger, Nigeria, Reunion Island, Rwanda, Sao Tome and Principe, Senegal, Seychelles, Sierra Leone, Swaziland, Tanzania, Togo, Uganda, Zambia, Zimbabwe, Comoros, Mayotte, Somalia, Libya

(*3) Asia + Oceanía: Israel, Bangladesh, Bhutan, Burma, Brunei, Nepal, Sri Lanka, Armenia, Azerbaijan, Georgia, Kazakhstan, Kyrgyzstan, Turkmenistan, Uzbekistan, Singapore, Thailand, Taiwan, Mongolia, Hong Kong, Philippines, Indonesia, Malaysia, Japan, South Korea, India, Saudi Arabia, Bahrain, United Arab Emirates, Jordan, Kuwait, Lebanon, Oman, Pakistan, Qatar, China, Laos, Macau, East Timor, Vietnam, Afghanistan, North Korea, Palestinian Territories, Iraq, Tajikistan, Cambodia, Iran, Russia, Australia, Norfolk Island, New Zealand, Cook Islands, Fiji, Guam, Northern Mariana Islands, Kiribati, Marshall Islands, Micronesia, New Caledonia, Palau, Papua New Guinea, French Polynesia, Solomon Islands, Samoa, American Samoa, Tuvalu, Vanuatu, Wallis and Futuna, Maldives, Tonga, Nauru, Niue, French Southern Territories.

(*4) North America: USA, Mexico, Canada, Saint Pierre and Miquelon

(*5) Central + South America + Islands: Puerto Rico, Belize, Costa Rica, El Salvador, Guatemala, Haiti, Honduras, Nicaragua, Dominican Republic, Chile, Argentina, Brazil, Bolivia, Panama, Paraguay, Peru, Uruguay, Venezuela, Colombia, Ecuador, Anguilla, Antigua and Barbuda, Aruba, Bahamas, Barbados, Bermuda, Dominica, Grenada, Guadeloupe, Guyana, Virgin Islands, Jamaica, Martinique, Montserrat, Saint Martin, Saint Vincent and the Grenadines, Saint Lucia, Trinidad and Tobago, Netherlands Antilles, South Georgia and the South Sandwich Islands, Maldives, Saint Barthelemy, Turks and Caicos Islands, Cayman Islands, Saint Kitts and Nevis, US Virgin Islands, Cuba, French Guiana, Suriname.

(*6) Nordic Islands: Iceland, Greenland, Faroe Islands.

GENERAL SPECIFICATIONS

• Engine brand KOHLER KDI
• KOHLER alternator trademark
• Voltage (V) 400/230
• Dashboard: APM303
• Optional Box: APM403
• Optional Box: M80
• Optional Box: Terminal strip 5 5
• Cooling type: Radiator
• Realisation type: G2

DIMENSIONS COMPACT VERSION

• Length (mm) 1410
• Width (mm) 720
• Height (mm) 1020
• Tank capacity (L) 50
• Net weight (kg) 340

DIMENSIONS SOUNDPROOFED VERSION M126

• Soundproofing type M126
• Length (mm) 1750
• Width (mm) 775
• Height (mm) 1230
• Tank capacity (L) 50
• Net weight (kg) 510
• Sound pressure level @1m in dB(A) 50Hz (75% PRP) 67
• Sound pressure level @7m in dB(A) 54

Exhaust system

• Exhaust gas temperature (°C) 443
• Exhaust gas flow (l/s) 41.90
• Max. exhaust back pressure (mm H2O) 750
• Cooling system
• Engine and radiator capacity (l) 5
• Fan power (kW) 0.35
• Fan air flow rate (m3/s) 0.65
• Radiator back pressure (mm H2O)
• Type of cooling Glycol-Ethylene

General

• COMPREHENSIVE DATA
• Ref. Alternator KH00350T
• Phase number Three-phase
• Power factor (Cos Phi) 0.80
• Altitude (m) 0 to 1000
• Excess speed (rpm) 2250
• Number of poles 4
• Ability to maintain a short circuit at 3 In for 10 s Yes
• Insulation class H
• T° class (H/125°) in continuous operation 40°C H / 125°K
• T° class in emergency operation 27°C H / 163°K
• Total harmonic distortion at no load DHT (%) 2,6
• AVR Adjustment Yes
• Total harmonic distortion on DHT load (%) 2,3
• Waveform: NEMA=TIF <45
• Waveform: IEC=FHT <2
• Number of bearings
• Direct Coupling
• Voltage regulation at the set speed (+/- %) 1
• Response time (Delta U = 20% transient) (ms) 200
• Protection class IP 2
• Brushless and ring-free technology

Alternator specifications

• KOHLER alternator trademark
• Ref. Alternator KH00404T

Other information

• Continuous rated power 40°C (kVA) 11
• Emergency power 27°C (kVA) 11.80
• Yield 100% load (%) 85.90
• Air flow rate (m3/s) 0.0550
• Short circuit report (Kcc) 0.90
• Longitudinal unsaturated synchronous R. (Xd) (%) 220,40
• Unsaturated synchronous cross-sectional R. (Xq) (%) 70,50
• Vacuum transient TC (T'do) (ms) 790
• Longitudinal transitional saturated ratio (X'd) (%) 18,70
• Transient CT in Short Circuit (T'd) (ms) 36
• Longitudinal sub-transitory saturated ratio (X''d) (%) 13,30
• Sub-transient TC (T "d) (ms) 13
• Saturated subtransitory cross-sectional ratio (X "q) (%) 69,60
• Sub-transient TC (T "q) (ms) 8
• Unsaturated homopolar r. (Xo) (%) 6.15
• Saturated inverse r. (X2) (%) 16
• Armature CT (Ta) (ms) 46
• No-load excitation current (io) (A) 0.34
• Excitation current on load (ic) (A) 1.46
• Excitation voltage on load (uc) (V) 22.90
• Start-up (Delta U = 20% perm. or 30% trans.) (kVA) 29.50
• Transient Delta U (4/4 load) - Cos Phi : 0.8 AR (%) 14.07
• No-load losses (W) 359
• Heat dissipation (W) 1444
• Maximum unbalance rate (%) 100
