Engine Kohler KDW1404 Diesel Expand

Kohler Diesel Engine KDW 1404

Kohler Kohler

New

engine KDW1404 from Kohler equipped with the best technology of the brand to face different functions and uses. Available in several versions.

  • kW (HP) 24.5 (33.3) @3600
  • engine water-cooled
  • Four strokes
  • 4 cylinders in line
  • Stage V (complies with EU pollutant regulations)
  • Compatible with KDW1404 spare parts
  • 3-year manufacturer's warranty

More details

Available

€6.523,50 tax incl.

€6.523,50 tax excl.

Caja Transporte Asvarta

Camión Transporte Asvarta

Express 2/3 days for europe. Ask us regarding delivery time for others countries

Paga a través de PayPal

Paypal secure payment

Distribuidores Oficiales Kohler y Lombardini

Kohler and Lombardini official distributors

Kohler KDW 1404

This Kohler engine has the brand's best performance for its various uses and versions. Among all its versions, we find its hydraulic version, generator version, engine pump version and silenced versions.

Specifically, this equipment is recommended for the different uses listed below.

Uses for Kohler Engine KDW1404

  • Lawn mower
  • Orchard/Vineyard tractor
  • Fruit/harvest picker
  • Wood chipper - Concrete mixer
  • Concrete spraying machine
  • Vibration plate
  • Generating set
  • Refrigeration units
  • Motorized sweeper
  • Aerial platform
  • Stringing equipment
  • High pressure washer

Engine equipped with feet, no radiator, no fuel tank, no exhaust and no starter box. Three power take-offs available

Lenght 599
Height 519
Width 412
Height 98
Rotation Clockwise direction
Aspiration Natural
Displacement (cc) 1372
Cooling System Liquid
Cylinders 4
Fuel Diesel
Power 24.5 (33.3) @3600
Range KDW FOCS/CHD

Among the different versions of the KDW 1404 engine, you will find the ones specified below.

Note: Make sure you choose your model correctly when ordering.

Version Spec Number KW/HP PTO / Fan RPM
Standard SDMO Genset ED339004SV00000-01 18.8 / 25.6 SAE 5 6 1/2” Flanging Suction Fan 3000rpm
Hydraulic Powerpack ED439002SV00000-01 18.8 / 25.6 Group 2 Hydarulic Adapter Suction fan 3000rpm
Water-Pump / Genset ED437019SV00000-01 18.8 / 25.6 SAE 5 7 1/2" Flanging Suction Fan 3000rpm
Silence version 1500RPM ED438005SV00000-01 18.0 / 24.5 Interchangeable Gr. 8-9 Flanging Suction Fan 1500rpm
Silence version 3000RPM ED639004SV00000-01 11.0 / 10.5 SAE 5 6 1/2" Flanging Blower Fan H.C. Oil Sump 3000RPM
