-5% Generating Set XP K16H Alize Kohler SDMO Expand

Generating Set XP K16H Alize Kohler SDMO

Kohler-SDMO Kohler-SDMO

New

This Kohler SDMO XP K16H Alize generating set has very long life for professional applications.

Find more information on this generator for professional activities below.

Certificado Calidad Kohler SDMO

More details

Available

€10.427,20 tax incl.

€10.427,20 tax excl.

€10.976,00

Caja Transporte Asvarta

Camión Transporte Asvarta

Shipping in 5 working days for Europe. Ask us regarding delivery time for others countries

Paga a través de PayPal

Paypal secure payment

Distribuidores Oficiales Kohler y Lombardini

Kohler and Lombardini official distributors

Generating Set XP K16H Alize Kohler SDMO

Range INDUSTRIAL: Leading edge technology, designed for regular, intensive use, that is powerful and quiet.

Several supported uses:

  • Ideal for small vehicles
  • For cultivators
  • Agriculture
  • Do-it-yourself
  • Construction
  • Industrial purposes

Find more SDMO generators in our SDMO Spain catalogue to find the alternative you are looking for.

Advantages SDMO XP K16H Alize

  • Entire group guaranteed 3 years
  • KOHLER water-cooled industrial engine
  • Complete control panel
  • Low noise level
  • Large Autonomy

Add-ons included with XP K16H Alize

  • User and maintenance manual
Lenght 175
Height 123
Width 77,50
Height 480
Cylinders 3
Fuel Petrol
Power 12.80kWe
Range XP
Frequency 50Hz
Nominal voltage (V) 230
Tank (L) 50
75% cons (l/h) 3,60
Sound power level guaranteed LwA dB(A) 95
Acoustic pressure level @1m in dB(A) 79
Acoustic pressure level @7m in dB(A) 66
Max power (kW) 12,80
Max power (kVA) 16

ENGINE SPECIFICATIONS

  • Engine brand: KOHLER KDI
  • Engine ref.: KDW1003
  • Air inlet system: Athmo
  • Cylinders configuration: L
  • Number of cylinders: 3
  • Displacement (L): 1,03
  • Bore (mm): 75
  • Stroke (mm): 77,60
  • Compression ratio: 22,8 : 1
  • Speed (RPM): 3000
  • Pistons speed (m/s): 7,76
  • Maximum stand-by power at rated RPM (kW): 16,50
  • Frequency regulation, steady state (%): +/- 2.5%
  • Governor type: Mechanical
  • Consumption @ 75% PRP load (L/h) *: 3,60
  • Oil system capacity including filters (L): 2,40
  • Oil consumption 100% ESP 50Hz (L/h): 0,08

ALTERNATOR SPECIFICATIONS

  • Alternator commercial brand: KOHLER
  • Alternator ref.: KH00260T

ENGINE SPECIFICATIONS

  • Engine brand: KOHLER KDI
  • Engine ref.: KDW1003
  • Air inlet system: Athmo
  • Cylinders configuration: L
  • Number of cylinders: 3
  • Displacement (L): 1,03
  • Bore (mm): 75
  • Stroke (mm): 77,60
  • Compression ratio: 22,8 : 1
  • Speed (RPM): 3000
  • Pistons speed (m/s): 7,76
  • Maximum stand-by power at rated RPM (kW): 16,50
  • Frequency regulation, steady state (%): +/- 2.5%
  • Governor type: Mechanical
  • Consumption @ 75% PRP load (L/h) *: 3,60
  • Oil system capacity including filters (L): 2,40
  • Oil consumption 100% ESP 50Hz (L/h): 0,08

ALTERNATOR SPECIFICATIONS

  • Alternator commercial brand: KOHLER
  • Alternator ref.: KH00260T
